| Frame | Size: XS Alpha Silver Aluminium, curved top tube, internal derailleur and dropper post routing, rack and kickstand mount, 135×5 mm ThruSkew Size: S , M , ML , L , XL , XXL Alpha Silver Aluminium, internal derailleur and dropper post routing, rack and kickstand mount, 135×5 mm ThruSkew |
|---|---|
| Fork | Size: XS , S RockShox Judy, coil spring, preload, TurnKey lockout, 42 mm offset for 27.5″ wheel, 100 mm QR, 100 mm travel Size: M , ML , L , XL , XXL RockShox Judy, coil spring, preload, TurnKey lockout, 46 mm offset for 29″ wheel, 100 mm QR, 100 mm travel |
| Front hub | Size: XS , S , M , ML , L , XL , XXL Formula DC-20, alloy, 6-bolt, 100 mm |
| Rear hub | Size: XS , S , M , ML , L , XL , XXL Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135×5 mm QR |
| Rear skewer | Size: XS , S , M , ML , L , XL , XXL 173×5 mm QR |
| Rim | Size: XS , S , M , ML , L , XL , XXL Bontrager Kovee, double-wall, Tubeless-Ready, 28-hole, 23 mm width, Presta valve Size: M , ML , L , XL , XXL Bontrager Kovee, double-wall, Tubeless-Ready, 32-hole, 23 mm width, Presta valve |
| Tyres | Size: XS , S Maxxis IKON, tubeless ready, EXO casing, folding bead, 60 tpi, 27.5×2.35” Size: M , ML , L , XL , XXL Maxxis Rekon Race, tubeless ready, EXO casing, folding bead, 60 tpi, 29×2.35″ |
| Rim strip | Size: XS , S , M , ML , L , XL , XXL Bontrager TLR |
| Shifter | Size: XS , S , M , ML , L , XL , XXL Shimano U6000, 10-speed |
| Rear derailleur | Size: XS , S , M , ML , L , XL , XXL Shimano CUES U6000 GS |
| Crank | Size: XS , S , M , ML Shimano U4000, 30T chainring, 170 mm length Size: L , XL , XXL Shimano U4000, 30T chainring, 175 mm length |
| Bottom bracket | Size: XS , S , M , ML , L , XL , XXL Shimano, 73 mm, threaded cartridge, 122.5 mm spindle |
| Cassette | Size: XS , S , M , ML , L , XL , XXL Shimano CUES LG300, LINKGLIDE, 11-48, 10-speed |
| Chain | Size: XS , S , M , ML , L , XL , XXL Shimano LG500 |
|---|---|
| Pedals | Size: XS , S , M , ML , L , XL , XXL VP-536 nylon platform |
| Saddle | Size: XS , S , M , ML , L , XL , XXL Bontrager Verse Short, stainless steel rails |
| Seatpost | Size: XS , S TranzX JD-YSI34, 100 mm travel, internal routing, 34.9 mm, 350 mm length Size: M TranzX JD-YSI34, 125 mm travel, internal routing, 34.9 mm, 405 mm length Size: ML , L , XL TranzX JD-YSI34, 150 mm travel, internal routing, 34.9 mm, 456 mm length Size: XXL TranzX JD-YSI34, 170 mm travel, internal routing, 34.9 mm, 500 mm length |
| Handlebar | Size: XS Bontrager alloy, 31.8 mm, 5 mm rise, 690 mm width Size: S Bontrager alloy, 31.8 mm, 15 mm rise, 720 mm width Size: M , ML , L , XL , XXL Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width |
| Grips | Size: XS , S , M , ML , L , XL , XXL Trek Line Comp, nylon lock-on |
| Stem | Size: XS , S Bontrager Comp, 31.8 mm, 7-degree, 35 mm length Size: M , ML , L Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length Size: XL Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 60 mm length Size: XXL Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 70 mm length |
| Headset | Size: XS , S , M , ML , L , XL , XXL Semi-integrated, 1-1/8″ |
| Brakes | Size: M , ML , L , XL , XXL Shimano MT200 hydraulic disc |
| Brake rotors | Size: XS , S , M , ML , L , XL , XXL Shimano RT26, 6-bolt, 160 mm Size: M , ML , L , XL , XXL Shimano RT26, 6-bolt, 180 mm |
| Brake set | Size: XS , S , M , ML , L , XL , XXL Shimano MT200 hydraulic disc |
