| Frame | Alpha Gold Aluminium, internal cable routing, rack & mudguard mounts, post mount disc, kickstand mount, 135×5 mm QR |
|---|---|
| Fork | FX alloy, flat-mount disc, rack mounts, 410mm axle-to-crown, ThruSkew 5mm QR |
| Hub front | Formula DC-20, alloy, 6-bolt, 5×100 mm QR |
| Skewer front | 139×5 mm bolt-on |
| Hub rear | Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135×5 mm QR |
| Skewer rear | 152×5 mm QR |
| Rim | Bontrager Connection, double-wall, 32-hole, 20 mm width, Schrader valve |
| Tyre | Bontrager H2 Comp, wire bead, 30 tpi, 700×35 mm |
| Shifter | Shimano U4000, 9-speed |
| Rear derailleur | Shimano CUES U4000 |
| Crank | ProWheel Pro alloy, 40T narrow-wide steel ring, 170 mm length |
| Bottom bracket | Sealed cartridge, 68 mm |
| Cassette | Shimano LINKGLIDE LG300, 11-46, 9-speed |
| Chain | Shimano LG500 |
|---|---|
| Pedal | Bontrager City pedals |
| Saddle | Bontrager Sport Women’s |
| Seatpost | Size: S, M Bontrager alloy, 27.2 mm, 12 mm offset, 330 mm length Size: XL, L Bontrager alloy, 27.2 mm, 12 mm offset, 400 mm length |
| Handlebar | Size: S, M Bontrager alloy, 31.8 mm, 15 mm rise, 600 mm width Size: XL, L Bontrager alloy, 31.8 mm, 15 mm rise, 660 mm width |
| Grips | Trek Line Ergonomic Comp, lock-on |
| Stem | Size: S, M Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 90 mm length Size: XL, L Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 100 mm length |
| Brake rotor | Tektro wave, 6-bolt, 160 mm |
| Brake Set | Tektro HD-R280 hydraulic disc, 160 mm rotor |
Good to know: manufacturers sometimes change specs, components, colours and graphics during a model year, so what you receive may differ slightly from the photos. If a detail matters to you, ask us before you buy and we'll check it for you.
