| Frame | 500 Series OCLV Carbon, IsoSpeed, internal storage, tapered head tube, internal cable routing, 3S chain keeper, mudguard mounts, flat mount disc, 142×12 mm thru axle |
|---|---|
| Fork | Domane SL carbon, tapered carbon steerer, internal brake routing, mudguard mounts, flat-mount disc, 12×100 mm thru axle |
| Weight | 56 – 9.09 kg / 20.05 lbs (with TLR sealant, no tubes) |
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb). |
| Shifter | Shimano 105 R7120, 12-speed |
| Front derailleur | Shimano 105 R7100, braze-on, down swing |
| Rear derailleur | Shimano 105 R7100, 36T max cog |
| Crank | Size: 44, 47, 50 Shimano 105 R7100, 50/34, 165 mm length Size: 52, 54, 56 Shimano 105 R7100, 50/34, 170 mm length Size: 58, 60, 62 Shimano 105 R7100, 50/34, 172.5 mm length |
| Bottom bracket | Praxis, T47 threaded, internal bearing |
| Cassette | Shimano 105 7101, 11-34, 12-speed |
| Chain | Shimano SLX M7100, 12-speed |
| Max. chainring size | 1x: 48T, 2x: 52/36 |
| Hub front | Bontrager alloy, sealed bearing, CenterLock disc, 100×12 mm thru axle |
| Skewer front | Bontrager Switch thru-axle |
| Hub rear | Bontrager alloy, sealed bearing, CenterLock disc, Shimano 11-speed freehub, 142×12 mm thru axle |
| Skewer rear | Bontrager Switch thru-axle, removable lever |
| Rim | Bontrager Paradigm 23, Tubeless Ready, 24-hole, 23 mm width, Presta valve |
| Spokes | 14 g stainless steel, black |
|---|---|
| Tyre part | Bontrager TLR sealant, 180 ml/6 oz |
| Max tyre size | 38 mm without mudguards, 35 mm with mudguards (as measured, see manual for details) |
| Saddle | Verse Short Comp, steel rails, 145 mm width |
| Seatpost | Size: 44, 47, 50, 52, 54, 56 KVF aero carbon seat post, 20 mm offset, 280 mm length Size: 58, 60, 62 KVF aero carbon seat post, 20 mm offset, 320 mm length |
| Handlebar | Size: 44, 47 Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 36 cm control width, 40 cm drop width Size: 50, 52 Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 38 cm control width, 42 cm drop width Size: 54, 56, 58 Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 40 cm control width, 44 cm drop width Size: 60, 62 Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 42 cm control width, 46 cm drop width |
| Handlebar tape | Trek EcoTack |
| Stem | Size: 44 Trek RCS Pro, -7-degree, 60 mm length Size: 47 Trek RCS Pro, -7-degree, 70 mm length Size: 50 Trek RCS Pro, -7-degree, 80 mm length Size: 52, 54 Trek RCS Pro, -7-degree, 90 mm length Size: 56, 58 Trek RCS Pro, -7-degree, 100 mm length Size: 60, 62 Trek RCS Pro, -7-degree, 110 mm length |
| Brake rotor | Size: 44, 47, 50, 52, 54, 56, 58, 60, 62 Shimano CL700, CentreLock, 160 mm Size: 44, 47, 50, 52, 54, 56, 58, 60, 62 Shimano RT70, CentreLock, 160 mm |
| Rotor size | Max brake rotor sizes: 160 mm front and rear |
